高配版耐碎石冲击检修机（High End Version Of Gravel Impact Testing Machine）

推行设施:

GMW 1407，JIS M0141，TL211-6，GME 60 268，ASTM/D3170，SAE J400，FORD，Chrysler 463PB-39-01，GMW14668-3.4.9，Chrysler 463PB-52-01，GM 9119P/9508P/9619P，Mazda MES MN 601C，Nissan，Volkswagen，Toyota，ISO 20567-1

Execution Standards:

GMW 1407，JIS M0141，TL211-6，GME 60 268，ASTM/D3170，SAE J400，FORD，Chrysler 463PB-39-01，GMW14668-3.4.9，Chrysler 463PB-52-01，GM 9119P/9508P/9619P，Mazda MES MN 601C，Nissan，Volkswagen，Toyota，ISO 20567-1

张开剩余94%

高配版耐碎石冲击检修机技能参数：

PLC限定系统

操作界面：中英文切换；

测试软件：可良友免费升级

试样沿路设定为喷射面积；

喷射时代可竖立0-999秒并喷掷中竖立时代暂停时代

漏斗不锈钢制作可安装0-10公斤傍边喷射介质

限定系统和试样箱可分辨，机动，可唐突移动位置

3D检修箱:SAE 45°冲击箱与VDA 90°冲击箱二合一，无需更换，90°，54°，里面竖立防撞软材

加配气动蜕变系统

喷射介质：钢珠，鹅卵石，砂砾等

试样尺寸：宽度≦195mm\厚度≦35mm\长度≦240mm（可把柄不同家具配不同夹具和试样尺寸）

喷射速率可调0-1Mpa ；

放射量可调遣，启齿可随便调遣

碎石直径 6mm

压力调遣界限0-1000kPa

速率调遣界限≥120km/h

放射量调遣界限≥1kg/min

放射角度调遣界限 45～90°

喷射压力界限：0-1MPA可定制其他高压力

试样测试角度：平板式的测试试样可按45°、90°，54° ，潦草正的试样继承3D检修箱

喷射头：45°和90°

高配版:165*60*131

螺杆式空压阴事求：

1.使用环境：室温，＜80%RH；

2.气体介质：空气；

3.电机功率： 7.5kW；

4.排气压力： ≥1.25Mpa；

5.排气量：＞1m³/min；

6.使用电源： 220V/50Hz；

7.传动神志：直连传动；

8.开动神志：变频开动；

9.储气罐：材质：不锈钢；容积：0.6m³/8kg (桶深高度＜2000mm)；需配安全阀、 压力表；桶身直径*高度： 700*1905mm

10.保护安装：需有高温、高压、堵塞、过流、缺相、逆相、电压不稳等保护安装。

Technical Parameters:

PLC control system

Operation interface: Switch between Chinese and English;

Testing software: can be remotely upgraded for free

All samples are set as spray area;

The spraying time can be set from 0-999 seconds and a pause time can be set during spraying

The funnel is made of stainless steel and can accommodate spray media weighing around 0-10 kilograms

The control system and sample box are separable, flexible, and can be moved to any position as desired

3D test chamber: SAE 45 ° impact chamber and VDA 90 ° impact chamber in one, no need to replace, 90 °, 54 °, equipped with anti-collision soft materials inside

Add pneumatic vibration system

Jet media: steel balls, pebbles, gravel, etc

Sample size: width ≤ 195mm, thickness ≤ 35mm, length ≤ 240mm (different fixtures and sample sizes can be matched according to different products)

Spray speed adjustable from 0-1MPA

The emission amount can be adjusted, and the opening can be freely adjusted

Gravel diameter 6mm

Pressure regulation range 0-1000kPa

Speed adjustment range ≥ 120km/h

Emission adjustment range ≥ 1kg/min

Launch angle adjustment range of 45-90 °

Spray pressure range: 0-1MPA, customizable for other high pressures

Sample testing angle: Flat test samples can be tested at 45 °, 90 °, 54 °, and irregular samples can be tested using a 3D test chamber

Spray head: 45 ° and 90 °

High end version: 165 * 60 * 131

Requirements for screw air compressors:

1. Operating environment: Room temperature,< 80%RH；

2. Gas medium: air;

3. Motor power: 7.5kW；

4. Exhaust pressure: ≥ 1.25Mpa；

5. Exhaust volume:> 1m³/min；

6. Use power supply: 220V/50Hz；

7. Transmission mode: direct transmission;

8. Startup method: Variable frequency startup;

9. Gas storage tank: material: stainless steel; Capacity: 0.6m ³/8kg (barrel depth and height<2000mm); Safety valves and pressure gauges are required; Barrel diameter * height: 700*1905mm

10. Protective devices: High temperature, high voltage, blockage, overcurrent, phase loss, reverse phase, unstable voltage and other protective devices are required.

高配版耐碎石冲击检修机旨趣：

高配版耐碎石冲击检修机通过放射高速气流和投射高速碎石来模拟汽车在行驶经由中际遇的碎石冲击情况。斥地经常由一个阻滞的检修室、用于放射气流的喷嘴和用于投射碎石的投射安装构成。通过限定气流速率、压力和碎石投射速率等参数，不错模拟不同强度的碎石冲击‌。

Principle:

The High-end Version Of The Gravel Impact Testing Machine simulates the impact of gravel encountered by cars during driving by emitting high-speed airflow and projecting high-speed gravel. The equipment usually consists of a closed laboratory, a nozzle for emitting airflow, and a projection device for projecting crushed stones. By controlling parameters such as airflow velocity, pressure, and gravel projection speed, it is possible to simulate gravel impacts of different intensities.

高配版耐碎石冲击检修顽皮骗限度：

‌建筑行业‌：在建筑行业中，高配版耐碎石冲击检修机主要用于评估混凝土等建筑材料的抗冲击性能。通过模拟碎石撞击，不错评估材料在复杂环境下的耐用性和安全性，确保工程质料‌。

‌谈路和桥梁汲引‌：在谈路和桥梁汲引中，高配版耐碎石冲击检修机用于测试沥青、混凝土等材料的抗冲击才调。精确的测试闭幕有助于工程师遴荐合适的材料，确保谈路和桥梁的历久性和安全性‌。

‌矿山和冶金行业‌：在矿山和冶金行业中，高配版耐碎石冲击检修机用于测试千般矿石和合金材料的耐磨性。通过模拟碎石冲击，不错评估材料的耐磨损性能，匡助企业在家具研发和坐褥中保抓朝上地位‌。

‌汽车行业‌：在汽车行业中，高配版耐碎石冲击检修机用于测试汽车外壳涂层的抗砂砾和碎石碰撞才调。这关于评价涂层的柔韧性、各层间的黏效劳和配套性止境要紧‌。

‌航空航天‌：在航空航天限度，高配版耐碎石冲击检修机用于评估航空材料的抗冲击性能。通过模拟高空中的碎石撞击，确保材料在顶点条款下的耐用性和安全性‌。

Application Areas:

Construction industry: In the construction industry, the High-end Version Of The Gravel Impact Testing Machine is mainly used to evaluate the impact resistance performance of building materials such as concrete. By simulating the impact of crushed stones, the durability and safety of materials in complex environments can be evaluated, ensuring the quality of the project.

Road and bridge construction: In road and bridge construction, the High-end Version Of The Impact Resistance Testing Machine is used to test the impact resistance of materials such as asphalt and concrete. Accurate test results help engineers choose suitable materials to ensure the durability and safety of roads and bridges.

Mining and metallurgical industry: In the mining and metallurgical industry, High-end Anti Crushing Impact Testing Machines are used to test the wear resistance of various ores and alloy materials. By simulating the impact of crushed stones, the wear resistance of materials can be evaluated, helping enterprises maintain a leading position in product research and production.

Automotive industry: In the automotive industry, High-end Anti Gravel Impact Testing Machines are used to test the anti gravel and gravel collision ability of car shell coatings. This is very important for evaluating the flexibility, adhesion between layers, and compatibility of coatings.

Aerospace: In the aerospace field, the High-end Version Of The Gravel Impact Testing Machine is used to evaluate the impact resistance of aerospace materials. By simulating the impact of gravel in high altitude, ensure the durability and safety of materials under extreme conditions.

功能：

高精度限定系统‌：继承先进的伺服电机与精密延缓器组合，合作闭环反应限定系统，完了对冲击力的精确调遣，罪恶率限定在千分之一以内，确保每一次冲击王人合乎预设设施‌。

‌千般化碎石模拟‌：内置多种规格与材质的碎石样本库，用户可把柄实质需求遴荐或自界说碎石类型，诱导可调遣的投石机构，完了碎石大小、局势、速率的机动设定，昂然千般化测试需求‌。

‌高速数据收罗与分析‌：配备高灵巧度传感器阵列，约略及时捕捉并记载冲击经由中的各项数据，如冲击力峰值、抓续时代、能量漫衍等。诱导高大的数据分析软件，为科研东谈主员提供详确的数据复古，助力材料性能优化‌。

‌安全防备与自动化操作‌：继承多重安全防备措施，如伏击停机按钮、过载保护、防备罩蓄意等，确保操作主谈主员安全。同期，复古良友限定与自动化操作，提升测试成果，缩小东谈主为罪恶‌。

‌千般化测试阵势‌：斥地继承先进的电脑限定系统，约略精确疗养检修参数，提供多种检修阵势，如目田落体冲击、定速冲击和多点冲击等，昂然不同用户的需乞降多种材料的测试要求‌。

‌及时监测和数据记载‌：斥地约略及时监测和记载千般数据，包括冲击力、冲击高度、试样袭击情况等，通过高精度传感器，用户不错精确获得检修闭幕，确保数据的可靠性和科学性‌。

‌大容量存储安装‌：斥地配备大容量存储安装，用户不错松开导出数据，便于后续分析和记载‌。

Function:

High precision control system: using advanced servo motors and precision reducers combined with closed-loop feedback control system to achieve precise adjustment of impact force, with an error rate controlled within one thousandth, ensuring that each impact meets the preset standards.

Diversified gravel simulation: Built in gravel sample library with multiple specifications and materials, users can choose or customize gravel types according to actual needs, combined with adjustable stone throwing mechanism, to achieve flexible setting of gravel size, shape, and speed, meeting diverse testing needs.

High speed data acquisition and analysis: Equipped with a high-sensitivity sensor array, it can capture and record various data during the impact process in real time, such as peak impact force, duration, energy distribution, etc. Combining powerful data analysis software to provide detailed data support for researchers and assist in optimizing material performance.

Safety protection and automation operation: Multiple safety protection measures are adopted, such as emergency stop button, overload protection, protective cover design, etc., to ensure the safety of operators. At the same time, it supports remote control and automated operations to improve testing efficiency and reduce human errors.

Diversified testing modes: The equipment adopts an advanced computer control system, which can accurately adjust the test parameters and provide multiple testing modes, such as free fall impact, constant velocity impact, and multi-point impact, to meet the needs of different users and the testing requirements of various materials.

Real time monitoring and data recording: The equipment can monitor and record various data in real time, including impact force, impact height, sample damage, etc. Through high-precision sensors, users can accurately obtain test results, ensuring the reliability and scientificity of the data.

Large capacity storage device: The device is equipped with a large capacity storage device, allowing users to easily export data for subsequent analysis and recording.

赞成器用：

90度喷头、45度喷头、眼罩1付、耳罩（耳塞）1个、直径19MM玄色的气管5米1根、（钢珠、鹅卵石选配）、2个卡箍23-25--若配储气罐（304补芯（1.5寸*1寸）1只和外丝1寸浮屠推敲20mm装配好）

Auxiliary Tools:

90 degree nozzle, 45 degree nozzle, 1 pair of eye mask, 1 ear cup (earplug), 1 black trachea with a diameter of 19MM, 5 meters long, (steel ball, pebble optional)万博manbext网页版登录app官网, 2 clamps 23-25- if equipped with a gas storage tank (1 304 core (1.5 inches * 1 inch) and outer wire 1 inch pagoda joint 20mm assembled)
